Mini Converter Audio to SDI

The Blackmagic Design Mini Audio to SDI Converter embeds analog or AES/EBU digital audio into 3G/HD/SD-SDI signals at up to 1080p60 resolution. Up to four channels of balanced analog audio or eight channels of AES/EBU audio can be connected via the four 1/4" jack inputs located on one side of the unit.
In addition to the dedicated SDI input, the converter also features a redundant SDI input, which allows a backup signal to be passed through in case the first one is lost. This is useful in broadcast-critical applications, especially outdoors or in crowded locations where there is a greater chance of cable damage or signal loss.
![]() |
Avacab Oficial Reseller |
The Blackmagic Design Mini Audio to SDI Converter embeds analog or AES/EBU digital audio into 3G/HD/SD-SDI signals at up to 1080p60 resolution. Up to four channels of balanced analog audio or eight channels of AES/EBU audio can be connected via the four 1/4" jack inputs located on one side of the unit.
In addition to the dedicated SDI input, the converter also features a redundant SDI input, which allows a backup signal to be passed through in case the first one is lost. This is useful in broadcast-critical applications, especially outdoors or in crowded locations where there is a greater chance of cable damage or signal loss.
![]() |
Avacab Oficial Reseller |
Request a product query
![]() |
Avacab Oficial Reseller |
This model allows you to integrate SDI audio with a maximum resolution of DCI 2K 25p. These signals are received from devices such as mixers and analog recorders via 0.25 "connections for balanced analogue audio channels or AES / EBU. This device offers an ideal solution when it is not possible to purchase a UHD model.
Connections
SDI Video Input
- Switchable between SD, HD, and3G-SDI.
SDI Video Output
- Automatically matches the SD, HD, and3G-SDI video input.
Analog Audio
- 4 channels of professional balanced analog audio with standard 1/4 inchjack connections.
AES/EBU Digital Audio
- 8 channels of professional balanced digital with standard 1/4 inch jack connections.
SDI Redundant Input
- Automatically switches over if main SDI input is lost.
Multi Rate Support
- Auto detection of SD, HD, 2K or 3G-SDI.
Updates and Configuration
- Via USB 2.0 high speed. (480 Mb/s)
Reclocking
- Yes
Data sheet
- Video Inputs
- SDI
- Outputs
- SDI
- Supported Resolutions
- 625i / 525i - SD
1280x720 - HD
1920x1080 - HD
2048x1080 - 2K - Entradas Audio
- AES/EBU
Balanceado - Data and Control
- USB
